High‑Speed Fully Automatic Baby Wet Wipes Production Line

High-Speed Baby Wet Wipes Production Line

---

Key Features
Fully automated end-to-end production system
High-speed output for large-scale manufacturing
Precise liquid dosing with consistent wetness control
Flexible folding and packaging formats
PLC + full servo control system
Touchscreen HMI interface for easy operation
Hygienic stainless steel construction
Error detection and safety shutdown system
Suitable for OEM and private label production

---

Overview
This high-speed baby wet wipes production line is designed for industrial-scale hygiene manufacturing. It integrates all production stages into a single automated system, from folding and wetting to cutting, stacking, and final packaging.

---

Performance & Automation
The machine operates with PLC and full-servo control, ensuring high precision, stable performance, and consistent product quality. It supports adjustable sheet counts and multiple packaging sizes, making it suitable for different market requirements.

---

Build & Hygiene Standards
Constructed with food-grade 304 stainless steel, the system meets strict hygiene and GMP standards. It is designed for easy cleaning, long-term durability, and safe production of personal care products.

---

Applications
Baby wet wipes production
Personal hygiene wipes manufacturing
Adult care wipes
Cleaning and disinfectant wipes
OEM/private label production

---

Why Choose This Production Line?
✔ Extremely high production capacity
✔ Fully automated operation
✔ Precise moisture and sheet control
✔ Flexible product formats
✔ Hygienic GMP-compliant construction

---

Technical Specifications
Production Capacity: 2,800–4,800 sheets/min or up to 80 packs/min
Tissue Material: Spunlace non-woven (35–80 gsm) or biodegradable options
Fold Types: Z-fold / N-fold / W-fold
Unfolded Size: 70–170 mm (W) × 160–220 mm (L)
Folded Size: 70–170 mm (W) × 80–110 mm (L)
Pack Size Range: 150–300 mm × 50–120 mm × 10–100 mm
Sheet Count: 20–120 sheets per pack (adjustable)
Wetting System: On-line liquid dosing ±3 g accuracy
Control System: PLC with full servo + HMI touchscreen
Material: Food-grade 304 stainless steel
Power: AC 380V, 50/60Hz (11–18 kW)
Dimensions: Approx. 13,000 × 2,600 × 1,950 mm
Weight: ~6,150 kg
Air Supply: 0.6–0.8 MPa compressed air

---

Applications
Large-scale baby wet wipes production
Hygiene product manufacturing
OEM/private label production
GMP-compliant industrial facilities

---
