Full Automatic Fresh Fruit Mango Juice Processing Line Automatic Juice Washing Filling Capping 3in1 Machine
This machine is specially designed for filling juice, tea drinks, and energy drinks in PET bottles and glass bottles.
It is an integrated equipment combining bottle washing, filling, and capping functions.
Details Images
Specifications
| Model | Capacity (B/H) | Power (KW) | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| RCGF 14-12-5 | 3000 | 2.2 | 2300 × 1600 × 2500 | 2600 |
| RCGF 18-18-6 | 5000 | 3.5 | 2600 × 1920 × 2550 | 3650 |
| RCGF 24-24-8 | 8000 | 4.5 | 3100 × 2100 × 2800 | 4800 |
| RCGF 32-32-10 | 12000 | 6 | 3850 × 3000 × 2850 | 6800 |
| RCGF 40-40-10 | 15000 | 7.5 | 4850 × 3800 × 2750 | 8500 |
| RCGF 50-50-12 | 18000 | 9.5 | 2300 × 1600 × 2500 | 10000 |
Bottle Blowing System
We supply the complete bottle blowing system, starting from the PET preform injection molding machine and bottle blowing machine, including:
- Air compressor system
- Water cooling system
Water Treatment System
According to the customer’s water source analysis report and the final water standard required, we suggest suitable water treatment systems to help reduce material consumption and maintenance costs.
Juice Processing System
We supply different juice processing system designs according to customer product requirements, including:
- Syrup melting system
- Beverage blending system
- Homogenizer and sterilizer
- HFSC storage system
- Ingredient dosing system
- Hot water system
- CIP cleaning system
Sterilization System
According to customer output, bottle capacity, material, and other requirements, we customize a suitable sterilization plan for the customer.
