Electric Screening Machine
Key Attributes
| Attribute | Details |
|---|---|
| Production Capacity (kg/h) | 100 – 10000 |
| Warranty | 1 Year |
| Key Selling Points | High Productivity |
| Core Components | Motor |
| Weight | 120 KG |
| Brand Name | ZHRU |
| Dimension (L × W × H) | 1950 × 780 × 530MM |
| Type | Vibration Screening |
| Use | Vibration Screening |
| Video Outgoing-Inspection | Provided |
| Machinery Test Report | Provided |
| Sieve Size (mm) | 150 × 60 |
| Power (kw) | 0.75 |
Packaging And Delivery
| Specification | Details |
|---|---|
| Selling Units | Single Item |
| Single Package Size | 195 × 78 × 53 cm |
| Single Gross Weight | 120.000 kg |
Working Principle
The linear screen uses a vibration motor as a vibration source to throw the material on the screen and move forward linearly.
The material is discharged from the feed port through multiple layers of screens to produce several sizes of upper and lower screen outlets.
The whole machine has the characteristics of low energy consumption, high output, simple structure, easy maintenance, no dust spillage, automatic discharge, and is also suitable for assembly line operations.
Scope Of Application
The all-stainless steel linear screen can screen and grade materials in powder, block, granular, and other forms.
It is widely used in food processing, grain selection, hardware grinding materials, chemical grading, and other industries, as well as assembly line grading and heat dissipation operations.
Key Features
- The whole machine is made of stainless steel with a flat and smooth surface.
- Strong toughness, high temperature resistance, and corrosion resistance.
- Strong vibration provides high screening efficiency.
- Equipped with a high-strength shock-resistant motor with long service life.
- Adjustable square feed port for more convenient feeding.
- Feed port size can be adjusted for different screening conditions.
- High-precision stainless steel sieve plate for easy and quick replacement.
- Screen mesh quantity can be customized.
- Wear-resistant sieve plate with long service life.
- Enlarged discharge port for smooth screening without blockage.
- Discharge port size and direction can be customized according to site conditions.
Machine Specifications
| Specification | Details |
|---|---|
| Machine Model | ZHRU-200 / 300 / 400 / 500 |
| Voltage | 110 / 220 / 380V |
| Power Type | Customizable Single-Phase or 3-Phase |
| Material | Thickened 304 Stainless Steel & Carbon Steel |
| Applicable To | Grains / Hardware / Black Fly Larvae / Yellow Mealworms / Materials Requiring Grading or Impurity Removal |
| Size & Weight | 1000 × 550 × 500 (Different Models) |
| Output | 200 – 20000 |
