Commercial DC Fast EV Charging Station

Commercial DC Fast EV Charging Station

---

Product Overview

The Commercial DC Fast EV Charging Station is a powerful and versatile solution designed to meet the growing demand for efficient electric vehicle charging infrastructure. Featuring dual DC charging connectors and intelligent power management, this system enables simultaneous charging while optimizing performance.

Built for commercial and public environments, the station supports fast charging, user-friendly operation, and integrated payment functionality. Its durable design and advanced control system ensure reliable performance even in high-traffic installations.

---

Introduction

With the rapid expansion of electric mobility, businesses require reliable and scalable charging solutions. The Commercial DC Fast EV Charging Station is engineered to deliver high-performance charging with intelligent system control and flexible output management.

The unit is equipped with dual CCS2 connectors, allowing two vehicles to charge simultaneously. When a single vehicle is connected, the system delivers maximum power output, while dual charging distributes power efficiently between both outputs.

Featuring a 7-inch touchscreen interface, multiple communication protocols, and RFID-based payment capability, this charging station is ideal for commercial deployment in public and private environments.

---

Specifications

Specification	Details
Product Type	DC Fast EV Charging Station
Charging Type	DC Fast Charging
Output Connectors	2 DC Charging Guns (CCS2)
Maintenance	Low Maintenance
Protection	Advanced Electrical Safety Systems
Installation	Floor Mounted
Input Voltage	Three Phase 380V ±20%
Display Interface	7-Inch LCD Touch Screen
Communication Protocol	OCPP 1.6 (Ethernet)
Communication Interface	CAN and RS485
Payment System	RFID IC Card Reader
Cooling Method	Intelligent Air Cooling
Operating Temperature	-40°C to +65°C

---

Key Features

Dual CCS2 charging connectors for simultaneous vehicle charging
Intelligent power distribution (80 kW single / 40 kW dual output)
OCPP 1.6 support for smart network integration
7-inch touchscreen interface for intuitive operation
RFID payment system for commercial monetization
Wide operating temperature range for outdoor use
Intelligent air cooling system for stable performance
Advanced communication interfaces for system monitoring
Reliable and durable construction for high-traffic environments
Fast charging capability reduces vehicle downtime

---

Applications

Commercial EV charging stations
Shopping centers and retail parking areas
Office parks and business complexes
Fleet charging depots
Hotels and hospitality venues
Residential estates and developments
Public transport hubs
