Automatic Stretch Wrap Turntable Machine (TP1650F-L) with Scale
Product Overview
The TP1650F-L Automatic Stretch Wrap Turntable Machine is designed for efficient pallet wrapping in industrial environments. It securely wraps palletized loads with stretch film, improving stability during storage and transportation.
With fully automatic operation and optional weighing scale integration, this machine is ideal for warehouses, logistics centers, and distribution facilities that require fast, consistent, and reliable packaging performance.
Specifications
| Specification | Detail |
|---|---|
| Model | TP1650F-L |
| Type | Automatic stretch wrap turntable |
| Turntable Size | 1650 mm |
| Machine Weight | 550β700 kg (variant dependent) |
| Wrapping Size | 1.1 Γ 1.2 Γ 2 m |
| Max Load Weight | 2000 kg |
| Power Supply | 110V / 220V / 380V, 50Hz |
| Wrapping Capacity | 10β30 loads/hour |
| Turntable Speed | 0β12 RPM (adjustable) |
| Machine Size (LΓWΓH) | 2545 Γ 1650 Γ 2785 mm |
| Operation | Fully automatic |
| Structure | Heavy-duty industrial frame |
Key Features
- Fully automatic pallet stretch wrapping system
- Integrated turntable design for stable load handling
- Optional scale system for weight measurement during wrapping
- Adjustable wrapping speed and rotation control
- Strong structure supporting up to 2000 kg loads
- Efficient film usage for cost reduction
- Customizable configuration (turntable, column, functions)
- Suitable for continuous industrial operation
Applications
- Warehousing and storage centers
- Logistics and freight operations
- Distribution hubs
- Manufacturing and export packaging lines
- Industrial pallet securing and shipment preparation
Summary
The TP1650F-L Automatic Stretch Wrap Turntable Machine provides a reliable and efficient solution for pallet packaging. With automatic operation, adjustable speed control, and strong load capacity, it improves packaging speed, reduces labor costs, and ensures stable and secure shipment preparation in industrial environments.
