Automatic Footwear Injection Molding Machine (Slipper Sole Production)
Product Overview
This automatic machine is a robust solution for footwear manufacturers specializing in slippers, flip-flops, and sandals. Using injection molding technology, it efficiently produces soles from materials such as EVA, PVC, and rubber, supporting a wide range of designs and specifications.
Designed for high productivity and precision, the system integrates computerized and PLC controls to ensure accurate movements and consistent output. It can be equipped with air-blowing systems for lightweight products and servo systems for improved energy efficiency, making it suitable for modern industrial footwear production lines.
Specifications
| Attribute | Value |
|---|---|
| Model | JL-108 (common reference) |
| Machine Type | Automatic Injection Molding Machine |
| Materials Processed | EVA, PVC, Rubber |
| Products Made | Slippers, Flip-Flops, Sandals (soles) |
| Control System | Computer + Electrical Box + PLC Control |
| Work Stations | 12 / 16 / 20 / 24 / 30 (configurable) |
| Clamping Force | 80 TON |
| Opening Stroke | 210 mm |
| Mould Dimension | 600 × 280 mm (typical) |
| Screw Diameter | 60 / 65 / 70 mm |
| Max Injection Volume | 650–1000 cm³ |
| Injection Speed | 10 cm/s |
| Screw Rotation Speed | 0–200 RPM |
| Total Power | 25.5 kW (normal) / 30.2 kW (servo) |
| Power Consumption | 15–20 kWh (normal) / 7–10 kWh (servo) |
| Optional Features | Air blowing system, servo system, cooling system |
| Warranty | 1–2 years (varies by supplier) |
Key Features
- High-efficiency automated sole production system
- PLC and computerized control for precise operation
- Multi-station design for high-volume manufacturing
- Supports EVA, PVC, and rubber materials
- Optional servo system for energy saving
- Air-blowing option for lightweight product output
- Stable and consistent molding performance
- Suitable for continuous industrial production
Applications
- Slipper and flip-flop manufacturing plants
- Sandal sole production industries
- Footwear OEM and export factories
- Large-scale EVA/PVC footwear production lines
Summary
This automatic footwear injection molding machine provides a complete and efficient solution for sole production. With high output capacity, flexible configurations, and advanced control systems, it is ideal for manufacturers aiming to scale production while maintaining consistent quality and reduced operating costs.
