Automatic Horizontal Stretch Wrapper Orbital Stretch Wrapping Machine

R344 498,81

SKU: GTM-2025022820274 Category: Industrial Machinery

Description

Automatic Horizontal Stretch Wrapper Orbital Stretch Wrapping Machine

Briefing

The product is an Automatic Horizontal Stretch Wrapper Orbital Stretch. This machine is designed for efficient and automated use in various industrial settings, combining advanced technology with high-quality materials.

Key Specifications

Type: Horizontal Stretch Wrapper
Material: High-quality materials
Operation: Fully Automatic
Weight: Varies based on model
Dimensions: Customizable
Design Style: Modern and Functional

Applications

Warehousing: Ideal for use in warehousing to secure palletized loads.
Logistics: Suitable for use in logistics to ensure safe transportation of goods.
Distribution Centers: Perfect for organizing and securing items in distribution centers.
Customizable: Can be customized for different sizes and specifications.

Summary

This automatic horizontal stretch wrapper orbital stretch offers a powerful and efficient solution for enhancing the security and stability of palletized loads. It is designed for fully automated operation, making it suitable for various industrial environments. The machine is customizable in terms of size and specifications, providing flexibility for different needs. Its durable construction and modern design ensure reliable performance and a touch of sophistication.

Product Description

The SP1000 horizontal stretch wrapping machine is a machine designed for sheets, doors, floor board, window, furniture, steel bundles, sandwich board. The wrapped package is well-protected, sealed, and looks more tidy. The machine can be connected to the packing line for automatic wrapping. Also, the horizontal wrapping packaging machine can equip the sealing cutting unit to achieve 6 sides wrapping.

Horizontal Stretch Wrapping Machine Specification

Device Name: Horizontal stretch wrapping machine
Model: SP1000
Cargo width: 300–650mm (customized according to product size)
Cargo height: 350–650mm (customized according to product size)
Packaging material width: 100–300mm
Packaging speed: 19–57 rpm
Roller carrying capacity: 100–1000kg
Total power/voltage: 3kw/380/50Hz
Overall weight: 1000 kg
Conveyor line width: 900mm
Conveying speed: 6–12m/min
Optional packaging materials: wrapping film, composite paper, woven tape
Matchable: Drum conveyor line, rubber wrapping drum line, belt conveyor line

Details Display

Cost savings: Photoelectric sensor automatically senses pallet height in auto mode with safety trip switch for extra security assurance.
Maximum pre-stretching ratio: up to 250%, saving wrapping film usage.
High quality spare parts: Three independent motors for stronger and longer life span control; uses Panasonic, Omron and other high quality spare parts.
Fully automatic system: Automatically apply, break, and touch film after wrapping packaging; improves work efficiency, reduces work intensity, and reduces costs by 60%.
Pressing device + precise positioning: Double chain lifting system for more safety; nylon tugs ensure long machine life (over 10 years).
Conveyor line options: conveyor line/drum/belt, plate cutting machine, coordinate stacker, foot feeder.
