Overview
This automatic boom barrier system features a brushless motor for high-efficiency performance and extended durability.
With adjustable arm length up to 6 meters and rapid open/close speeds, it ensures smooth traffic control in outdoor environments.
Equipped with RFID access control and anti-pinch functionality, it’s suitable for high-traffic areas requiring secure, reliable entry management.
Specifications
| Attribute | Details |
|---|---|
| Motor Type | Brushless DC Motor |
| Material | Aluminium Alloy, Stainless Steel |
| Barrier Arm Length | 1.5m to 6m |
| Opening/Closing Time | 0.8–6 seconds (based on arm length) |
| Access Type | RFID Card |
| Control Interface | RS485 |
| Function | Anti-pinch, One-way Operation |
| Operating Voltage | DC 24V |
| Power Consumption | 120W |
| Protection Level | IP44 / IP55 |
| Rated Working Temperature | -30°C to 60°C |
| Operating Life | Over 5 Million Cycles |
Key Features
Brushless Motor
Long-lasting, low-maintenance design.
Adjustable Speed
0.8–6s opening time depending on barrier arm length.
Anti-Pinch Function
Enhanced safety for vehicles and pedestrians.
Weatherproof Build
Rated for outdoor installation.
RFID Access Control
Compatible with various security systems.
Wide Operating Temperature
Performs reliably in extreme climates.
Applications
- Parking lots and garages
- Gated residential communities
- Industrial entrances
- Commercial building access points
- Campus and institutional gates
